72” Avro Lancaster Plan December 2006 by Tony Nijhuis


   Tony Nijhuis 72 Inch Lancaster

Specification

Wingspan
1829mm / 72"
Length
1295mm / 51"
IC Engine
Not recommended
Electric Motors
4-Max Recommended
Radio
5 Function
AUW
2948g / 6lbs 8oz

 Click here to download the RCM&E build article in PDF format

Please click here for the recommended electric setup

RC Groups forum for the Tony Nijhuis 72" Lancaster

Click here to view some build photos by Tony Nijhuis

The 72” electric Lancaster is one of the best selling plans of the RCM&E collection and is a real builders models.
This is the latest version of the plan with the improved more scale like outline and 2 piece wing. The plan features fully built up construction using balsa and plywood.
The fuselage is a simple slab sided structure with a rolled balsa top and a cross-sheeted underside. The wings are a built-up structure of ribs over a main spar and balsa sheeted. The tailplane is built up in a similar fashion to the wings.
Originally designed for four 400-6V geared motors and 16-cells but we now recomend a brushless setup with Lithiun Polymer batteries for the best flight performance and duration.
The model is designed for retractable undercarriage.
Plan, canopy, turrets, spinners and cowls are available as is a CNC pack and wood pack.
The CNC pack includes, ply fuselage formers, ply wing & tailplane ribs and the nacelle structure.

Please Note
Although we carry selective stock, we generally print and manufacture to order so deliveries may take up to 28 days to reach you from point of order. Also delivery of plans, some plastic parts and CNC wood packs will be sent as separate consignments.

For overseas orders please Email us

Description Price Quantity
Plan for 72" Lancaster £25.00
Vac form set (canopy, cowls, turrets and electric spinners) £34.00
Plan + Vac form set Save £3.00 £56.00
CNC Pack (ply fuselage formers, ply wing & tailplane ribs and the nacelle structure) £75.00
Plan + Vac form Set + CNC Pack Save £6.00 £128.00
Wood Pack to complete model (stock sheet and strip) £75.00
Plan + Vac form Set + CNC Pack + Wood Pack Save £10.00 £199.00
Air Retract Set for 72" Lancaster £195.00 Out of Stock
Electric Retract Set for 72" Lancaster £179.00
